Respect of the customer,please contact the sales staff before purchasing module to carry out pre-sale consultation.Otherwise,the module may not meet your needs or modules have no inventory. Detailed specifications docs,please download form the official website. skype:nickren999
6110R-IF is a highly integrated module with low power 802.11n Wireless LAN(WLAN) network controller.It combines an ARM-CM3 MCU, WLAN MAC, a 1T1R capable WLAN baseband, and RF function. It also provides a bunch of configurable GPIO which are configured as digital peripherals for different applications and control usage. 6110R-IF integrates internal memories for complete WIFI protocol functions.6110R-IF integrates 1MB ROM to provide high access speed, low leakage memory. The ROM memory clock speed is up to 166MHz.
Smart home, intelligent control products
CMOS MAC, Baseband PHY, and RF in the module for 802.11b/g/n compatible WLAN Complete 802.11n solution for 2.4G band 150Mbps receive PHY rate and 150Mbps transmit PHY rate using 40MHz bandwidth Standards Supported 802.11b/g/n compatible WLAN 802.11e QoS Enhancement(WMM) 802.11i(WPA,WP2). Open, shared key, and pair-wise key authentication services WiFi Direct support Light Weight TCP/IP protocol WLANPHYFeatures 802.11n OFDM
One Transmit and one Receive path(1T1R) 20MHz and 40MHz bandwidth transmission Short Guard Interval(400ns) Maximum data rate 54Mbps in 802.11g and 150Mbps in 802.11n HostInterface 2 x UART
